 船舶電站柴油機自動預熱供油泵
我公司生產的kcb齒輪泵,2cy齒輪泵,ycb圓弧齒輪泵,單螺桿泵,雙螺桿泵和三螺桿泵都通過了中國船級社CCS船檢認證.我公司所有的泵型都可以用在船舶電站用作供油泵,使用哪個泵需要根據客戶所需供油泵的壓力和流量覺得選擇什么型號的泵.Our
company produces the KCB gear pump, 2 cy gear pump, ycb arc gear pump, single
screw pump, double screw pump and the three screw pump has passed the certification
of China classification society CCS classification survey. My company all type
pump can be used in ship power station is used as for the oil pump, which pump
need according to the customer required for pressure and flow of oil pump think
to choose what type of pump.
kcb供油泵泵參數表:
型號 Model
| 流量
| 工作壓力
Mpa
| 吸入真空高度m
| 進出口口徑mm
| 轉速
Nr/min
| 電機功率
kw |
m 3 /h
| L/min |
|
| 1.1
| 18.3
| 1.45
| 5
| G 3 / 4 "
| 1400
| 1.5 |
|
| 2
| 33.3
| 1.45
| 5
| G 3 / 4 "
| 1420
| 2.2 |
|
| 3.3
| 55
| 0.33
| 5
| G1"
| 1400
| 1.5 |
KCB-83.3
| 5
| 83.3
| 0.33
| 5
| G 1 / 2 "
| 1420
| 2.2 |
KCB-135
| 8
| 135
| 0.33
| 3
| Φ50
| 1440
| 4 |
KCB-200
| 12
| 200
| 0.33
| 3
| Φ50
| 1440
| 4 |
KCB-300
| 18
| 300
| 0.36
| 3
| Φ70
| 960
| 5.5 |
|
| 29
| 483.3
| 0.36
| 3
| Φ70
| 1440
| 7.5 |
|
| 38
| 633
| 0.28
| 3
| Φ100
| 970
| 11 |
KCB-960
| 58
| 960
| 0.28
| 3
| Φ100
| 1470
| 18.5 |
KCB-1200
| 72
| 1200
| 0.28
| 2
| Φ150
| 740
| 37 |
|
| 96
| 1600
| 0.28
| 2
| Φ150
| 980
| 45 |
KCB-1800
| 110
| 1800
| 0.28
| 2
| Φ200
| 740
| 55 |
KCB-2500
| 150
| 2500
| 0.28
| 2
| Φ200
| 980
| 75 |
KCB-3800
| 230
| 3800
| 0.28
| 2
| Φ250
| 990
| 110 |
KCB-5400
| 325
| 5400
| 0.28
| 2
| Φ250
| 990
| 110 |
2.2CY供油泵參數表
型號 Model
| 流量
| 排出壓力 Mpa
| 吸入真空高度m
| 進出口口徑mm
| 轉速
Nr/min
| 電機功率Power kw |
m 3 /h
| L/min |
2CY-0.6
| 0.6
| 10
| 0.6/2.5
| 3
| G3/4"
| 1400
| 1.1/1.5 |
2CY-1.08
| 1.08
| 18
| 0.6/2.5
| 3
| G3/4"
| 1400
| 1.5 |
2CY-2.1
| 2.1
| 35
| 0.6/2.5
| 3
| C1"
| 1420
| 1.5/3 |
2CY-3
| 3
| 50
| 0.6/2.5
| 3
| C1"
| 1420/1440
| 2.2/4 |
2CY-4.2
| 4.2
| 70
| 0.6/2.5
| 3
| G11/4"
| 1440
| 4/5.5 |
2CY-7.5
| 7.5
| 125
| 0.6/2.5
| 3
| G11/2"
| 1440
| 5.5/7.5 |
2CY-10
| 10
| 167
| 0.6/2.5
| 3
| G11/2"
| 1440/1460
| 7.5/11 |
2CY-12
| 12
| 200
| 0.6/2.5
| 3
| G2"
| 1460
| 7.5/11 |
2CY-15
| 15
| 250
| 0.6/2.5
| 3
| G2.5"
| 1440/1460
| 7.5/15 |
2CY-18
| 18
| 300
| 0.6/2.5
| 3
| G2.5"
| 1440/1470
| 7.5/18.5 |
3.YCB供油泵參數表:
型號 Model
| 流量Flow Capacity
| 工作壓力
Mpa
| 吸入真空高度
m
| 進出口口徑
mm
| 效率
%
| 轉速
Nr/min
| 電機功率
kw |
m3/h
| L/m |
YCB 0.6/0.6
| 0.6
| 10
| 0.6
| 3
| Φ25
| 32
| 910
| 0.75 |
YCB 1.0/0.6
| 1.0
| 16.7
| 0.6
| 3
| Φ25
| 32
| 1390
| 0.75 |
YCB 1.6/0.6
| 1.6
| 26.7
| 0.6
| 3
| Φ32
| 42
| 910
| 0.75 |
YCB 2.5/0.6
| 2.5
| 42
| 0.6
| 3
| Φ32
| 42
| 1400
| 1.1 |
YCB 3.3/0.6
| 3.3
| 55
| 0.6
| 3
| Φ40
| 60
| 940
| 1.5 |
YCB 4/0.6
| 4
| 66
| 0.6
| 3
| Φ50
| 60
| 940
| 1.5 |
YCB 5/0.6
| 5
| 83.3
| 0.6
| 3
| Φ40
| 60
| 1420
| 2.2 |
YCB 6/0.6
| 6
| 100
| 0.6
| 3
| Φ50
| 60
| 1420
| 2.2 |
YCB 8/0.6
| 8
| 133
| 0.6
| 3
| Φ65
| 60
| 960
| 3 |
YCB 10/0.6
| 10
| 167
| 0.6
| 3
| Φ65
| 60
| 960
| 4 |
YCB 12/0.6
| 12
| 200
| 0.6
| 3
| Φ65
| 61
| 1440
| 5.5 |
YCB 15/0.6
| 15
| 250
| 0.6
| 3
| Φ65
| 61
| 1440
| 5.5 |
YCB 20/0.6
| 20
| 333
| 0.6
| 3
| Φ80
| 68
| 970
| 7.5 |
YCB 25/0.6
| 25
| 420
| 0.6
| 3
| Φ80
| 69
| 970
| 11 |
YCB 30/0.6
| 30
| 500
| 0.6
| 3
| Φ100
| 70
| 970
| 11 |
YCB 40/0.6
| 40
| 660
| 0.6
| 3
| Φ125
| 72
| 970
| 15 |
不同形式的供油泵有不同的結構,所以客戶在選型的時候,如有不名之處請聯系我公司,我公司將詳細的為您解答所有關于供油泵的知識.Different
forms of supply pump has different structure, so customers in the selection,
please contact me if there is any don't name the company, my company will be
detailed answers to all knowledge about supply pump for you.
